Batch Tutorial¶

Welcome to the Batch Job Tutorial. If you have never run a batch job before, or if you are looking for a review of the basics, this page should help you get up an running.

Batch Scripts¶

When you want to run analyses in batch mode, you need to inform the system of two things:

1. What Resources You Need: This includes specifying the number of CPUs, the amount of memory, GPUs, and other resources necessary to run your work. These instructions guide the system in selecting the appropriate compute resources and target compute nodes for your workflow. Continuing with our factory analogy, these resources can be thought of as the postal address on the outside of the envelope.

2. The Instructions to Execute: This is a list of commands that the compute node will follow once your workflow starts. These commands are written in Bash and include everything you would normally type on the command line if you were running your work interactively. For example, you would cd to the relevant working directory, module load any required software, source virtual environments, and so forth. In our analogy, these commands are like the schematics inside the envelope that you're sending to the factory.

Batch Script Structure¶

A batch script is a text file that is written with three sections:

1. The "shebang"
   will always be the line #!/bin/bash. This tells the system to interpret your file as a bash script. Our HPC systems use bash for all our environments, so it should be used in your scripts to get the most consistent, predictable results.
2. The directives section
   will have multiple lines, all of which start with #SBATCH. These lines are interpreted as Slurm directives by the scheduler and are how you request resources on the compute nodes, set your output filenames, set your job name, request emails, etc.
3. The code section
   in your script is a set of bash commands that tells the system how to run your analyses.

An example batch script might look like the following:

#!/bin/bash
# --------------------
### Directives Section
# --------------------
#SBATCH --job-name=hello_world
#SBATCH --account=<your_group>
#SBATCH --partition=standard
#SBATCH --nodes=1
#SBATCH --ntasks=1
#SBATCH --time=00:01:00
# --------------------
### Code Section
# --------------------
echo "Hello world, I am running on compute node $HOSTNAME"
# sleep only used for demonstration purposes
sleep 30

#!/usr/bin/env python3
print("Hello world!")

Submit Your Job¶

After writing your batch script, the next step is to submit it to the scheduler. The scheduler is software designed to coordinate jobs efficiently across the system. It reads the batch directives from the second section of your batch script (described above) and uses those resource requests to determine where to send your workflow. Continuing with our factory analogy, the scheduler acts like the postman, serving as the intermediary between you and the compute nodes (the factory) and handling all communication and resource scheduling.

To submit your batch job to the scheduler, use the sbatch command. This will return a Job ID, which works like a tracking number when you send a package via the post office. You can use your Job ID to monitor your analysis as it runs and retrieve resource usage data once it’s completed.

An example of using sbatch is shown below:

(puma) [netid@wentletrap ~]$ sbatch hello_world.slurm
Submitted batch job 10233657

We can then check on its status using the command squeue.

(puma) [netid@wentletrap ~]$ squeue --job 10233657
        JOBID PARTITION   NAME        PRIORITY   USER    ACCOUNT ST CPUS MIN_M NOD  NODELIST(REASON) TIME_LEFT
     10233657 standard    hello_worl      5001   netid   hpcteam PD    1    5G   1        (Priority) 1:00

The amount of time your job spends waiting before it starts running often is determined by various factors which include:

1. Job Size. This includes the number of CPUs, nodes, GPUs, etc. The more resources you request, the longer it may take before your job starts running.

2. Job Duration. Jobs with shorter runtimes will often start faster than long-running jobs.

3. Node Type. Our clusters have many standard nodes, fewer GPU nodes, and very few high memory nodes. The high memory nodes in particular may have very long wait times. If you do not need a lot of memory for your job (e.g., on Puma, less than 470 GB), it may be more efficient to run your work on a standard node. If your job has been stuck in the queue for a very long time, ensure that you have not accidentally targeted a high memory node.

4. Cluster Usage. The more jobs running on the cluster, the longer the wait times may be. To check how busy the cluster is, try running the command nodes-busy.

5. Maintenance. Quarterly maintenance cycles impact queue times. We will send announcements typically a week in advance of any planned maintenance cycles and will include announcement banners in our documentation. See our maintenance section for more information.

Submitting Multiple Jobs¶

Frequently, users need to submit multiple, related jobs. It may be tempting to do this using a bash loop, but there are several drawbacks to this method, primarily that it can affect the performance of the job scheduling software.

The best way to submit related jobs is to use job arrays. Jobs arrays allow users to submit multiple related jobs using a single script and single sbatch command. Each task within the array can have its own unique input parameters, making it ideal for running batch jobs with varied inputs or executing repetitive tasks efficiently. See Array Jobs for specifics on how to submit these sorts of workflows.

Retrieve Your Results¶

Once your job starts running, a file will be generated in the directory where you submitted your batch script. This file logs the job's standard output (stdout) as it runs—essentially, what would have been printed to the terminal if you had run the job interactively. The file is updated in real-time, so you can log into the cluster at any time to check your job's progress. By default, this file is named slurm-<jobid>.out, but you can customize the filename using batch directives if desired.

Let’s look at the output for our example job:

(puma) [netid@wentletrap ~]$ cat slurm-10233657.out
Hello world!

Conclusion¶

Batch jobs are a powerful way to automate your workflows on the HPC system, allowing you to efficiently use resources and manage long-running tasks without needing to stay logged in. By understanding how to write and submit batch scripts, you can run complex analyses, monitor their progress, and retrieve their results.

If you're just getting started, here are a few additional tips:

1. Start Small: Test your scripts with smaller jobs to ensure everything is working as expected before scaling up to larger, more resource-intensive tasks.
2. Explore More: Take some time to explore additional batch directives and experiment with different resource requests to optimize your jobs.
3. Ask for Help: Don’t hesitate to reach out to our HPC support team if you have any questions or run into issues. We're here to help you get the most out of the system.
